Rocking shakers Duomax 1030
Article number: 9839855
Product information "Rocking shakers Duomax 1030"
The Rocking shaker Duomax is suitable for the modular Incubator 1000 and is recommended for applications which require variable temperatures. With 2-dimensional tilting movement, suitable for petri dishes, culture bottles, erlenmeyer flasks and all standard vessels.
- An overtemperature sensor preventatively shuts off the unit in a dangerous heat-up situation, particularly valuable for you in case of continuous operation
- Insulated drive system prevents any heat-up coming from the motor and consequently thermal damage to your sample
- Designed with a low center of gravity which prevents gliding at high speed, even on a damp surface
- Set and continuously adjust the variable speed on the analog control knob, suitable for all standard vessels
- An analog process timer (max. 120 min) allows for unattended operation. When the set time has elapsed, an acoustic alarm will sound and the operation stops
Depth: | 375 mm |
---|---|
Depth moving table: | 258 mm |
Dimensions (WxDxH): | 320 x 375 x 185 mm |
Height: | 185 mm |
IP code: | IP 40 |
Inclination angle: | 5 ° |
Manufacturer Article Number: | 543-32205-00 |
Max. inclination angle: | 5 ° |
Max. loading capacity: | 5 kg |
Max. permitted ambient temperature: | 40 °C |
Max. relative humidity rate: | 80 % |
Max. speed: | 50 1/min |
Max. voltage: | 230 V |
Min. permitted ambient temperature: | 5 °C |
Min. speed: | 2 1/min |
Moving table (WxD): | 290 x 258 mm |
Permitted ambient temperature: | 5 ... 40 °C |
Power supply: | 230 V, 50/60 Hz |
Power supply frequency: | 50/60 Hz |
Rated capacity: | 115 W |
Speed: | 2 ... 50 1/min |
Type: | Duomax 1030 |
Type of movement: | Rocking |
Weight: | 8 kg |
Width: | 320 mm |
Width moving table: | 290 mm |
With timer: | Yes |
